TEZ-60II Model APG Clamping Machine

Epoxy resin automatic pressure gelation(APG) clamping machine is combined with hydraulic station and electric panel to produce epoxy resin insulation parts, like support insulator, insulating sleeve, contact spouting bushing, current transformer, voltage transformer etc. It features moulding, pressure holding, top core pulling, bottom core pulling, side injection, vertical and horizontal axis tilting, heating and automatic PID temperature control etc., suitable to be used for various epoxy resin insulators production.

Machine Features

•    Hydraulic and Electric system welded to the frame, convenient for transportation

•    Bottom core glider designed for durability & clean purposes

•    Stainless leakage-collecting tray

•    Top core stabilization structure design

•    Enlarged top carriage stoke for mold hoist

•    Tipping device in both X and Y axes

•    Annealing treatment of the main frame

•    Flat bottom board for easy access

•    Large opening distance for easy unloading & loading

•    Large Elliptical installation holes of top and bottom cores, adjustable for mold fixing

•    Safety grid and relay, avoiding accidents

•    PQ or servo system adopted to sets pressure and speed precisely

•    Reliable and international-branded electrical components

•    High-quality temperature sensor and heating rod, ensuring accurate tempt control

•    Non-contact solid relay or SCR module, low errors and easy diagnoses by CT detection

•    Remote controller and cantilever system, dual selection

•    PLC+10 inches TFT HMI control, simple operation

•    Intelligent PID temperature control system

•    Flexible in program revision, storage and commission

•    Aviation plugs and sockets for rapid installation

•    System network, remote control and monitoring are all available

•    Extendable mechanical and electrical functions

•    LED lighting during machine operation, great energy saving

•    Two temperature display modes with clear indicators or HMI

Why Top Electric? Here's our advantages:

- The most professional APG technology provider through machines and many years insulators production experiences.

- We know how important new project development for you, so we focus on providing APG clamping machine with one-stop service for every customers to give them a customized solution from mould development to insulators sampling.

- Our mold clamping machine with elegant outlook and delicate design. More than that, we always adopt top line brand and premium materials(such as thicker steel tube) in manufacturing process to ensure the reliability and stability of machine in long-term usage.

- All-purpose service for sampling, test and commissioning until client satisfaction, and provide APG technical know-how in production.

- Many years manufacturing and export experiences, way better understand the demands of customers, could strictly control and guarantee in production, commissioning, inland transportation, sea shipment, and overseas after-sale services.

- 24 months quality guarantee for machine based on top line brands and best materials adoption

YUEQING TOP ELECTRIC SCIENCE CO.,LTD

ADD: 138, W. NINGKANG RD, YUEQING, ZHEJIANG 325600 CHINA

Tel: 86-13646532050 86-577-27817182 Fax: 86-577-61660878

Website: http://www.top-electric.cn

We could also supply related products as ovens, moulds, epoxy resin materials etc., and provide APG technology training services as well.
