Hot Air Circulation Electric Oven

Product Numbers: 201392313515
Price: US $4000
Product description: Hot air circulation Electric Oven

INTRODUCTION

Hot air circulation Electric Oven

1. The RFD Series oven uses a unique hot air circulation duct structure, so the temperature uniformity, with a little temperature inside.

2. As a result of high-power multi-vane centrifugal fan, air flow, air flow through the surface faster, it can greatly improve the speed of drying the parts.

3. Put the heating element in an appropriate profile air flue in order to avoid the accidents caused by its directly contacting with agent of fusion air with low-ignition point.

4. The RFD series oven added a New Digital time relay, using a high precision digital temperature controller, to achieve the over-temperature protection, and expanded the scope of use, so the oven is more safe and reliable when it is working.

5. The small oven with a tray, the large oven with special rack or cart, so it will be much convenience for users.

Ⅲ、The RFD Electric Oven Specifications

Model	Studio size (L×W×H)	Fan power KW	Heating power KW	Rated voltage (v)	Operating temperature (℃)
RFD-3CS	600×500×700	0.12kw	2～3kw	220V	Room temperature～200
RFD-4CS	600×500×1000	0.25kw	3～4kw	220V	Room temperature～200
RFD-5CS	700×500×1200	0.55kw	4～5kw	220V	Room temperature～200
RFD-6CS	800×800×120	0.55kw	4～6kw	380V	Room temperature～250
RFD-7CS	800×800×1500	0.75kw	5~7kw	380V	Room temperature～250
RFD-8CS	1000×1000×1200	0.75kw	6～8kw	380V	Room temperature～250
RFD-9CS	1000×1000×1500	1.1kw	7～9kw	380V	Room temperature～250
RFD-10CS	1000×1200×1500	1.1kw	8～10kw	380V	Room temperature～250

Note: The fans of RFD-9CS and RFD-10CS are used three-phase power supply.
